- 1 year warranty on board and on battery
- Capacity : 1500VA/900W
- Voltage : 110/120 VAC or 220/230/240 VAC
- Frequency Range 60/50 Hz (Auto sensing)
- OUTPUT Voltage : 110/120 VAC or 220/230/240 VAC
- Waveform (Bat Mode)Simulated Sinewave
- Battery Type & Number 12V 7Ah*1
- Charging ability 4-6 hours recover to 90% capacity
- Full protection Overload, discharge, and overcharge protection ,short circuit
- Humidity 0-90% Relative Humidity 0-40 ℃ (Non-condensing)
- LCD DisplayAC input and AC output voltage , Frequency , Battery level , load level , fault
NCTS NU7110 UPS
UPS
Brand:NCTS
Model:NU7110
Capacity:1000VA/600W
Material:Plastic
Dimensions:280x100x140 mm
Weight:3.9 kg
INPUT
Voltage:110/120 VAC or 220/230/240 VAC
Voltage Range:86-145 VAC or 140-300 VAC
Frequency Range :60/50 Hz (Auto sensing)
OUTPUT Voltage :110/120 VAC or 220/230/240 VAC
AC Voltage Ragulation : ±10%
Frequency Range (Bat Mode):60Hz or 50Hz ± 1Hz
Transfer time:Typical 2-6ms
Waveform (Bat Mode):Simulated Sinewave
Power factor:0.6
Battery
Battery Type&Number:12V 7Ah*1
Floating Charging Voltage:13.7VDC
Charging ability:4-6 hours recover to 90% capacity
Protection
Full protection:Overload,discharge,and overcharger protection ,short cercuit
Led Indications
Line mode:Green lighting
Battery mode:Flashing every 4 seconds
Charging
Fault:Green lighting
Sound Alarm
Battery mode:Sound every 4 seconds
Low battery:Sound every 1 second
Fault:keep sounding
DiGiShi quarantees the quality of this products and it is secured from the approved source in the local markets in Syria
NCTS Uninterruptible Power Supply (UPS) 2000VA
Expert Features
- •Excellent microprocessor control optimizes reliability
- •Wide range of power input
- •boost and buck AVR for voltage stabilization
- •Auto restart while AC is recovering
- •Off mode charging function
- •Simulated sine wave
- •Cold start function
- •Perfect protection for overload ,short circuit ,over-voltage ,low-voltage and over-heating etc.
- •Display: LED display selection providing status, load and battery information
- •Intelligent battery management
Expert Technical Specs
| Model | STE2000 | ||||
| Capacity | 2000VA/700W | ||||
| INPUT | |||||
| Voltage | 110/120 VAC or 220/230/240 VAC | ||||
| Voltage Range | 81-145VAC or 162-290VAC | ||||
| Frequency Range | 60/50 Hz (Auto sensing) | ||||
| OUTPUT Voltage | 110/120 VAC or 220/230/240 VAC | ||||
| AC Voltage Ragulation (Bat Mode) | ±10% | ||||
| Frequency Range (Bat Mode) | 60Hz or 50Hz ± 1Hz | ||||
| Transfer time | Typical 2-6ms | ||||
| Waveform (Bat Mode) | Simulated Sinewave | ||||
| Battery | |||||
| Battery Type&Number | 12V 9Ah*2 | ||||
| Charging ability | 4-6 hours recover to 90% capacity | ||||
| Protection | |||||
| Full protection | Overload, discharge and overcharge protection | ||||
| INDICATIONS | |||||
| LCD Display | AC/Battery Mode, Load/Battery Level, Input /Output Voltage ,Overload, Fault, and low Battery | ||||
| LED Display | AC Mode | Green lighting | The right green LED lighting& the 2nd to 5th green LEDs gradually lighting indicating load level | ||
| Battery Mode | Yellow flashing | The right green LED flashing& the 2nd to 5th green gradually lighting indicating battery capacity | |||
| Fault | Red lighting | ||||
| Battery mode | Sounding every 10 seconds | ||||
| Low battery | Sounding every second | ||||
| Overload | Sounding every 0.5 seconds | ||||
| Battery Replacement Alarm | Sounding every 2 seconds | ||||
| Fault | Continuously sounding | ||||
| Dimension, D*W*H(mm) | 370*135*165 | ||||
| Net Weight (kgs) | 11.5 | ||||
| Environment | |||||
| Humidity | 0-90% Relative Humidity 0-40 ℃ (Non-condensing) | ||||
| Noisy Level | Less than 40dB | ||||
